ZH MODEL GL-QUEST-2200 AUTOMATIC SPECIALTY FOLDER GLUER

Description

86" ZH MODEL GL-QUEST M2800 AUTOMATIC SPECIALTY FOLDER GLUER EQUIPPED WITH VACUUM STREAM FEEDER,
MOTORIZED SETTING OF FOLDING RAILS, HHS 4 GUN GLUE SYSTEM (STANDARD),SERVO-DRIVEN BACK FOLD SYSTEM, AUTO-LOCK BOTTOM CAPABILITIES, 4 & 6 CORNER GLUING CAPABILITIES, SQUARING SYSTEM,COMPRESSION SECTION, E FLUTE - DOUBLEWALL AND
MONITOR WITH CAMERA

IMPROVEMENTS INCLUDE:

1-increase the length of the alignment section for better control
2-all sections changed from AC motor to servo motor
3- set up saving computer
4- light curtain on folding section
4- safety doors with interlock switches
5- Safety fence at squaring section
6- Optional Valco Glue Sytem offered
7-Remote connection device
(Never had to connect for any reason yet)
8- Bigger vacuum blower for feeder

ELECTRICAL REQUIREMENTS:
480 VOLTS
60 HZ
140 AMPS
TRANSFORMER PROVIDED FOR 380 VOLTS
